Dosing pump for industrial or laboratory

Generally:

The MDX is an industrial peristaltic pump for high-precision dosing. Its sophisticated design and LCD display provide real-time pump status, making operation extremely easy. This calibratable pump allows you to set various parameters: dosing volume, dosing time, pause time, suction angle, and speed.

Depending on the pump head and tubing diameter, the pump has a flow rate range of 0.03–6000 ml/min per channel, while the servo motor can reach 0.1–600 rpm in continuous transfer mode. A maximum of four channels are possible. This allows for a wide range of fluid transfer and dosing requirements, from laboratory use to industrial production.

Technical specification:

  • Speed ​​range: 0.1-600 rpm in 0.1 rpm increments
  • Flow rate: 0.03-6000 ml/min/channel
  • Speed ​​precision: 0.01 rpm
  • Dosing volume interval: 0.1-9999.99 ml
  • Filling accuracy: 0.5-1.0%
  • Flow rate: 0.1-6000 ml/min, depending on pump head and tubing diameter
  • Control: Membrane keypad for start/stop, stop, full speed, and CW/CCW buttons.
  • External control: Start/stop, speed (optional 0-5V, 0-10V, 4-20mA, RS485, RS232, MODBUS protocol), passive (e.g., a foot pedal), and active switching signals (5V, 12V, 24V).
  • Output interface: Motor status (open collector output)
  • Relative humidity: < 80%

A. Real-time volume display: Select the working mode in the system settings interface and display the data. In transferring mode, you can display the motor speed or flow rate. You can change the motor speed or flow rate by clicking the A area. If the dispensing mode is volumetric, you can display the filling volume or the total number of fillings in dispensing mode, and the current value will be displayed in real time when the system starts working. If the dispensing mode is speed dispensing, the current motor speed or the total number of fillings will be displayed.

B. Real-time dynamic display: Displays the dispensing and transfer status, and an animation shows the monitoring results. Click on the pump head to display the SN code and system version of this pump.

C. Real-time Parameter Display

(1) In Dispensing mode: Displays the dispensing volume (Dis. Volume mode) or the dispensing speed (Dis. Speed ​​mode), countdown of the current dispensing time, countdown of the current pause time, and copy numbers.

(2) In Transfer mode: Displays the current total transfer volume and current working time. The maximum transfer volume is measured at 9999L. The current working time is a maximum of 9999 hours. When the limit is reached, both data are reset to zero. You can also reset the data to zero in the system settings.

D. Setting Parameter Display: This area displays the current working status, pump height, tube size, and other parameters.

E. Date and Time Display: Displays the current date and time; click “E” to change them.

F. System Settings Button: Press this button to enter the system settings interface, including basic configuration, mode settings, communication settings, back-suck angle, and shared mode.

G. Flow Calibration Button: Press this button to enter the calibration interface.

H. Real-time Monitor Button: Press this button to enter the monitoring interface. Here, you can check the current flow rate, motor speed, and dispensing capacity settings. The monitoring function is prohibited during speed dispensing in dispensing mode.

I. Volume Dosing Button: Press this button to enter the volume setting interface. This function is prohibited in transmission mode.

J. Speed ​​Dispensing Button: Press this button to enter the dispensing speed interface; this function is not available in transmission mode.

K. Copy Number Button: Press this button to display the numeric keypad; enter the copy numbers. If you enter “0,” the number of copies is unlimited. This function is prohibited in transmission mode.
